Toggle Switches by Forbes & Lomax

$205.00
Finish: Unlacquered Brass
Gang
Model

Description

Forbes & Lomax’s Toggle Switches are based on the elegant nickel and brass light switches of the 1930s. These simple, timeless switches are a refined detail in any interior.

Toggle Switches are rated at 15 amps and come in 3-way and 4-way versions. 3-way switches can also be used as single pole switches. Toggle Switches can be mixed with Rotary Dimmers and push buttons on the same plate. Contact us for custom configurations.

Established in 1987, Forbes & Lomax is a UK based company with a reputation for high quality design amongst architects and designers.

Specifications

Switch: Ø 20 mm (0.79”)

1 Gang Plate: W 70 mm (2.76”) X H 115 mm (4.53”)
2 Gang Plate: 115 mm (4.53”) X 115 mm (4.53”)
3 Gang Plate: W 162 mm (6.38”) X 115 mm (4.53”)
4 Gang Plate: W 210mm (8.27”) X 115 mm (4.53”)

Available for:

Line Voltage (For use in conventionally wired installations)

  • 3-way, 15A (also works as Single-Pole)
  • 4-way, 15A (contact us)
Low Voltage: For use on Class 2 Circuits only
  • 2-Position Momentary Dry Contact Toggle (contact us)
  • 3-Position Momentary Dry Contact Toggle (contact us)
  • 3-Position Latching Dry Contact Toggle (contact us)

See full Technical Specification sheets below.

Note:

  • Toggle switches conform to UL 20 and are certified to CSA C22.2 No.111.
  • Please review and ensure all certifications are applicable for your local code.
  • Must be installed by a licensed electrician.
  • Toggle switches install into standard junction boxes but the boxes must be recessed below the finished wall surface by at least 1/8”. Please refer to the Wallbox Assembly Diagram in the Installation Guide below. If you are installing into existing junction boxes, you will probably find the boxes are already recessed by at least this much but please check to make sure before placing an order.

Areas of application: Light-duty Commercial, Residential

Material(s)

  • Unlacquered Brass
  • Aged Brass
  • Nickel Silver
  • Brushed Stainless Steel
  • Antique Bronze

Note: materials will slowly age or oxidize over time. Wipe clean with a dry, non-abrasive microfiber cloth. Avoid use of chemical or alcohol based cleaners. Refer to the care guide below for best practices.

Lead Time

3-4 week lead time. Please contact us for more information or for stock availability.

Product Downloads

Toggle Switch Product Sheet
Toggle Switch Installation Guide
Forbes and Lomax Brochure
Forbes and Lomax Care Guide
