The Bocci 22 System is a modular flush-mounted solution for power and data that sits cleanly within your surface, eliminating visible cover plates for a completely seamless look. Designed with precision and minimalism in mind, each component locks into a cylindrical mounting plate that installs directly into drywall, tile, wood, or other finish materials.

This product listing supports all installation types. The configurator below will walk you through selecting the correct combination of components for your specific surface, layout, and device needs.

The Bocci 22 System is a modular flush-mounted solution for power and data that sits cleanly within your surface, eliminating visible cover plates for a completely seamless look. Designed with precision and minimalism in mind, each component locks into a cylindrical mounting plate that installs directly into drywall, tile, wood, or other finish materials.

Drywall Configuration Overview

1. Mounting Surface:
Drywall

2a. Device Configuration:
Single or Double Device

2b. Device Orientation:
Side-by-side Narrow / Wide / Diagonal

3. Faceplate Colour:
White / Almond / Grey / Black

4. Device Type:

Outlets: 15A (120V), 20A High Amperage (120V)
USB / Media: USB-A, USB-C, HDMI
Data & Control (Request Quote): RJ45 CAT6A, RJ12, F Connector, Smart Home Keypad

Non-Drywall Configuration Overview

1. Mounting Surface:
Wood / MDF / Corian / Stone / Tile / Plaster

2a. Device Configuration:
Single or Double Device

2b. Device Orientation:
Side-by-side Narrow / Wide / Diagonal

3. Mounting Surface Thickness (Required for non-drywall only)

Short (6.35mm – 12.7mm): Mounting plate must be set 12.7mm behind the surface
Medium (12.7mm – 19.05mm): Mounting plate must be set 19.05mm behind the surface
Long (19.05mm – 31.75mm): Mounting plate must be set 31.75mm behind the surface

Tip: Measure from the finish face to the back of the substrate. If unsure, round up. View Barrel Depth Guide (PDF)

4. Faceplate Colour:
White / Almond / Grey / Black

5. Device Type:

Outlets: 15A (120V), 20A High Amperage (120V)
USB / Media: USB-A, USB-C, HDMI
Data & Control (Request Quote): RJ45 CAT6A, RJ12, F Connector, Smart Home Keypad

Tools & Accessories:

Removal Tool (Required: 1 per project)
Wood / MDF / Corian / Stone: Router Template for Double Device
Tile / Plaster: Trim Cap (1 per device)

Specifications

Ø 34 mm (1.3")
Certified: cUL to comply with CSA standards
GFCI Code Requirements: To comply with GFCI code, a GFCI breaker must be installed elsewhere along the circuit in an accessible, hidden location. This breaker must be purchased independently.
Tamper Resistant: Designed to enhance safety and prevent unauthorized access or interference
Finishes: White (RAL 9016), Black (RAL 9017), Almond (RAL 1013) and Grey (RAL 7038)

Product Downloads

General Information

Certification

Bocci 22 cUL Certificate (PDF)

Installation Instructions

Planning Guides

Material Selection Guide (Multi-Material)
Determine the correct mounting plate based on surface material.
Barrel Depth Selection Guide
Choose the correct barrel length based on thickness.
Component Removal Guide

Technical Drawings

Bocci 22 CAD Files

Component Data Sheets

Mounting Plates: Drywall

Mounting Plates: MDF / Wood / Stone / Tile / Corian

Devices: Standard

Devices: Request Quote

Tools & Accessories

Installation Videos

Multi-Material Install
Step-by-step guide for tile, plaster, Corian, or other mixed surfaces.

Drywall Install
Clean installation into drywall using standard Bocci 22 components.
