Face Mounted Bi-Part Barn Door Hardware

The Bi-Part Barn Door Hardware system offers a refined and functional solution for maximizing space efficiency and enhancing door management. This dual-door mechanism operates along a single continuous track, allowing two doors to slide in opposite directions for opening and meet seamlessly at the center when closed.

Crafted from durable materials such as brass and steel, this hardware ensures strength, reliability, and long-term performance. Available in multiple finishes — Brass, Raw Steel, Stainless Steel, and Black — it complements a range of contemporary and traditional interiors.

For specific layouts requiring greater flexibility, a Bypass configuration is also available.

Customization is at the core of our offering — we tailor each track to your exact specifications. To receive a detailed quote, please provide the following details:

• Style: Top Mount / Face Mount / Bi-Part
• Finish: Brass / Raw Steel / Stainless Steel / Black
• Required Length
• Drilling Option: Pre-drilled or Not Drilled

This bi-part sliding barn door hardware combines technical precision with minimalist design, ensuring a smooth, balanced operation and a seamless architectural finish.

Made and designed in Toronto by 1925Workbench.

Please Note: Not all finish and shape variants have corresponding images available for preview online.

Pre-Drilled vs. Non Pre-Drilled Holes

• Pre-drilling available — please specify when ordering. Choose pre-drilled or not pre-drilled based on installation requirements.
• Pre-drilled holes are spaced evenly every 14.75” – 17.25” along the track.
• Pre-drilled tracks must be mounted on a backing piece to ensure the door clears baseboards or moldings.
• Not pre-drilled tracks can be installed directly to the wall if baseboards are flush and adequate blocking is present behind the wall.

Track Length & Measuring

• To determine the correct track length: order at least twice the width of the door plus a minimum 2" overlap on each side.
• The door should be 4" wider than the opening (2" overlap per side) and large enough to cover door frames or casing if applicable.
• Tracks over 93" are shipped in two pieces.
• Recommended headroom (distance between top of opening and ceiling) is 8"-10". Minimum required headroom is 6".

Weight Capacity

• Rated for doors up to 200 lbs per pair of hangers. Actual load capacity may vary depending on wall structure and installation method.

Custom Finishes

• Please Note: For Black Powder Coated “Not Pre-drilled” orders, a 1.5″ hole will still be drilled at each end for hanging during the powder coating process.

Additional Components

• The Floor Guide is a small bracket mounted at the base of the door to keep it aligned during operation.
• While not required, a floor guide is highly recommended for stability and smooth motion.
• Available in two mounting styles:

1. Slot Guide
2. Clamp Guide

*Price includes hardware only. Door and header piece not included.
*Suitable for outdoor applications; finishes will patina more quickly when exposed to the elements.

Crafted from high-quality, authentic materials with minimal treatment to highlight their natural character.

• Stainless Steel – Hand-brushed finish, left largely untreated to showcase its raw beauty.
• Matte Black Metal – Durable powder-coated finish for a refined, modern look.
• Solid Brass – Brass-plated steel bolts for added strength. Finished with a light oil coat to preserve patina and extend longevity. Suitable for outdoor use, though patina will develop faster.
• Hot Rolled Steel – Naturally dark finish with minimal treatment, celebrating the material’s inherent depth and texture.

High-quality solid metal rollers with double built-in ball bearings ensure smooth, quiet motion.

1925 Workbench Face Mounted Barn Door Hardware Installation Guide (PDF)
1925 Workbench Face Mounted Barn Door Hardware Specifications (PDF)
