Qtoo Wall Mounted Touchless Soap Dispenser System
Pre-drilling or pre-milling for hardware components is not recommended until all items are received and measured. Learn more
There may be slight variations that could affect the installation of your hardware as many pieces are hand finished / fabricated.
Casson is not responsible for any damages or inconveniences resulting from the improper installation of the hardware.
Pairs With
Description
The Qtoo Wall-Mounted Touchless Soap Dispenser by d line is a built-in, sensor-activated soap dispensing system crafted from marine-grade AISI 316 stainless steel for seamless wall integration and long-term performance. Designed for bathrooms, powder rooms, and high-traffic commercial washrooms where hygienic, hands-free operation is required.
The sensor, pump, and refill container are housed within the wall for a clean, architectural finish. Pairs with the Qtoo Wall-Mounted Sensor Tap for a fully touchless handwashing system. Made in Europe.
What's Included
- QS3400 — In-Wall Rough-In Connector x 1
- Wall-Mounted Soap Refill Container x 1
- QSF04 — Gear Pump (Electronic) x 1
Specifications
- Rose Diameter: Ø 70 mm (2.76")
- Projection: 119 mm (4.69")
- Detection Distance: 5 cm ±10%
- Security Time: 2 seconds
- Dispenses: Liquid soap, hydroalcoholic gel, or liquid alcohol
- Viscosity Range: Up to 2200 cps
- pH Range: 6.5 to 9.5
- Output Per Dose: 0.8–1.2 ml
- Power Supply: Gear Pump QSF04
Materials
Marine-grade stainless steel (AISI 316). Lead-free and antibacterial.
Available Finishes
- Polished Stainless Steel
- Satin Stainless Steel
- PVD Satin Brass
- PVD Polished Brass
- PVD Satin Bronze
- PVD Satin Black
Certifications
- Lead-Free Compliant
- NSF/ANSI 61 Certified
- CSA B125.1 (2018)
- ASME Certified
- 20-Year Warranty on Stainless Components
- 5-Year Warranty on PVD Finishes
System Pairing
For a complete, touch-free washroom setup, pair with the matching Qtoo Wall-Mounted Sensor Tap. The matching finishes and streamlined form ensure a cohesive aesthetic while maximizing sanitation and ease of use.
Included Components
This dispenser set includes all required mechanical and electrical components for a complete wall-integrated installation:
- QS3400 – In-Wall Rough-In Connector × 1
- Wall-Mounted Soap Refill Container × 1
- QSF04 – Gear Pump (Electronic) × 1
