Name: Knud C Door Lever
Brand: d line
SKU: 14231602010
Price: 245.0 CAD
Availability: InStock

$245.00

Shipping calculated at checkout.

Finish — Satin Stainless Steel

Satin Stainless Steel

Polished Stainless Steel

PVD Satin Brass

PVD Satin Copper

PVD Satin Charcoal

Black RAL 9005

Quantity

CONTACT TO REQUEST QUOTE

Indicate finish, size, quantity, function or mounting type, and shipping address to receive a quote.

Estimated Ship Date: Stainless Steel 5-8 weeks | Other finishes 8-12 weeks

Optional Accessories

Description

The Knud C Lever is a minimal door leaver with a soft curve, suitable for both residential and commercial interiors. The coordinated line of minimalist architectural hardware from 1971 is ‘modest design that is designed to last’.

Knud Holscher graduated from the Royal Danish Academy of Fine Arts School of Architecture, having studied under Arne Jacobsen. d line levers are designed for constant use. They are rigorously tested and use the most cutting-edge machinery in the field. Each piece is expertly crafted by hand.

Made in Europe.

Specifications

Size: Ø 19 mm (3/4") / Ø 16 mm (5/8") lever handle
Door Thickness: 33 mm (1.3") - 59 mm (2.3")
Rose: Available with or without
Bore Hole: Ø25 mm
Cover Plate: Available with or without
Certifications: Tested and certified according to EN1906 and EN1634-1

Privacy/Lock Options:
Knud Toilet Indicator
Knud Toilet Indicator Long

Areas of application: Commercial, Residential

NOTE: European roses are smaller than standard North American models. Please ensure all dimensions are carefully reviewed as these may not fit existing or pre-bored door holes.

Material(s)

Satin Stainless Steel (AISI 304 with satin grain 320 finish)
Polished Stainless Steel
PVD coated Copper, Brass, or Charcoal on Stainless Steel
Powder coated RAL 9005 Black on Stainless Steel
X-BAC antimicrobial coating and finishes available upon request

Product Downloads

Knud C Lever Product Sheet
d line Brandbook
d line Passage Latch Options
d line Privacy Lock Options

Finish Swatches

2023 Updated d line finish swatches:

d line finish swatch examples

Finish Samples

Shop finish samples HERE.

Additional Components by Function

Ensure your lever handle functions seamlessly with the essential components listed below.

Passage Door

Passage doors do not have an internal locking mechanism, making them ideal for bedrooms, kitchens, and living rooms.

Our custom built sets require:
Lever / Knob + Euro Mortise Passage Latch Lock (60mm backset) + Spindle.

For tubular latch sets, we offer the Baton Tubular Passage Latch in 2 3/8" or 2 3/4" backset options. Ready-to-buy sets are available from the AHI Hardware collection.

Select Passage Mortise

Privacy Door

Privacy doors provide additional security with interior latches that lock without a key, perfect for bathrooms.

Our custom built sets require:
Lever / knob + thumb turn + Euro Mortise Bolt (60mm backset) + Spindle.

For tubular lock sets, we offer the Baton Tubular Latch and bolt in 2 3/8" or 2 3/4" backset options. Ready-to-buy sets are available from the AHI Hardware collection.

Select Privacy Mortise
Select Thumb Turn

Keyed Entry Door

Keyed entry door hardware is designed for exterior doors, providing secure access to buildings and homes.

Our custom built sets require:
Lever / Knob + Euro Mortise Keyed Lock (60mm backset) + 2 x Key Escutcheon + CES key cylinder + Spindle.

Select Keyed Entry Mortise
Select CES Key Cylinder
Select Key Escutcheon
