Bocci

Bocci 22: Flush Outlet System

Select your mounting surface, device configuration, and outlet type. Your setup will determine the required components to complete your set — accessories can be added as needed.

Final price is shown below once all components are selected.

This quantity reflects the number of complete sets being added to your cart.

$0.00
/
Shipping calculated at checkout.
  • Estimated Ship Date: 1-2 weeks
Description

The Bocci 22 System is a modular, flush-mounted solution for power and data that integrates directly into your surface—no visible cover plates, just a seamless finish. Each component locks into a cylindrical mounting plate designed for installation in drywall, tile, wood, stone, or other materials.

Thoughtfully engineered for precision and minimalism, the 22 System supports a variety of configurations. Use the configurator below to select the ideal components based on your surface, layout, and functional needs.

Don’t let standard cover plates disrupt your vision. The Bocci 22 System offers a refined, flush alternative that lets your backsplash, millwork, or stonework speak for itself.

UL-listed for use in Canada and the U.S.

Drywall Configuration Overview

1. Mounting Surface:
Drywall

2a. Device Configuration:
Single or Double Device

2b. Device Orientation:
Side-by-side Narrow / Wide / Diagonal

3. Faceplate Colour:
White / Almond / Grey / Black

4. Device Type:

  • Outlets: 15A (120V), 20A High Amperage (120V)
  • USB / Media: USB-A, USB-C, HDMI
  • Data & Control (Request Quote): RJ45 CAT6A, RJ12, F Connector, Smart Home Keypad
Non-Drywall Configuration Overview

1. Mounting Surface:
Wood / MDF / Corian / Stone / Tile / Plaster

2a. Device Configuration:
Single or Double Device

2b. Device Orientation:
Side-by-side Narrow / Wide / Diagonal

3. Mounting Surface Thickness (Required for non-drywall only)

  • Short (6.35mm – 12.7mm): Mounting plate must be set 12.7mm behind the surface
  • Medium (12.7mm – 19.05mm): Mounting plate must be set 19.05mm behind the surface
  • Long (19.05mm – 31.75mm): Mounting plate must be set 31.75mm behind the surface

Tip: Measure from the finish face to the back of the substrate. If unsure, round up. View Barrel Depth Guide (PDF)

4. Faceplate Colour:
White / Almond / Grey / Black

5. Device Type:

  • Outlets: 15A (120V), 20A High Amperage (120V)
  • USB / Media: USB-A, USB-C, HDMI
  • Data & Control (Request Quote): RJ45 CAT6A, RJ12, F Connector, Smart Home Keypad

Tools & Accessories:

  • Removal Tool (Required: 1 per project)
  • Wood / MDF / Corian / Stone: Router Template for Double Device
  • Tile / Plaster: Trim Cap (1 per device)
Specifications
  • Ø 34 mm (1.3")
  • Certified: UL-listed to U.S. safety standards 498 and 514D, the 22 System is approved for both Canadian and American installations.
  • GFCI Code Requirements: To comply with GFCI code, a GFCI breaker must be installed elsewhere along the circuit in an accessible, hidden location. This breaker must be purchased independently.
  • Tamper Resistant: Designed to enhance safety and prevent unauthorized access or interference
  • Finishes: White (RAL 9016), Black (RAL 9017), Almond (RAL 1013) and Grey (RAL 7038)
Product Downloads
General Information


Certification


Installation Instructions


Planning Guides


Technical Drawings


Component Data Sheets

Mounting Plates: Drywall

Mounting Plates: MDF / Wood / Stone / Tile / Corian

Devices: Standard

Devices: Request Quote


Tools & Accessories
Installation Videos

Multi-Material Install
Step-by-step guide for tile, plaster, Corian, or other mixed surfaces.

 

Drywall Install
Clean installation into drywall using standard Bocci 22 components.

 

Shop finish samples HERE.

This site is protected by hCaptcha and the hCaptcha Privacy Policy and Terms of Service apply.

This is a precise architectural product, and support is available. If you're unsure what to order, use the form above or email contact@cassonhardware.com — our team is happy to help.
